CT PT Analyzer HYVA-402V

HYVA-402V CT PT Analyzer is used to test current transformer and voltage transformer. It can finish CT volt-ampere curve test, CT Ratio and phase test, PT volt-ampere curve test, PT ratio and phase test, winding resistance measurement, CT/PT Transformation ratio test and phase error test.

Features
Technical Specification

Power supply

Output scope

Measuring   scope

Measuring accuracy

CT volt-ampere test

220V

02000V05A

02000V05A

2000VA

0.5%RGD0.05%FS

CT ratio and phase test

220V

0600V

0600V050mA

0.5%RGD0.05%FS

PT ratio and phase test

220V

0600V

0600V00.7V

0.5%RGD0.05%FS

PT volt-ampere test

220V

0130V

0130V

0.5%RGD0.05%FS

Winding resistance   test

220V

0.10.2A

050Ω

0.5%RGD0.05%FS

Working   power

AC220V±10% 50HZ

External dimensions

450×340×300

Weight

33.5KG
